Junction Box

GREY JUNCTION BOX 029

Color:Grey or Customized
Size:3.75"D x 4.50"W x 7.5"L



Round 20 Cu.In. PVC New Work Round Electrical Ceiling Box

Classification: Junction Box
Share:



             ETL/UL651 Pvc-u Electrical Junction box



 Modle   Round 20 Cu.In. PVC New Work Round Electrical Ceiling Box
 Raw material   PVC
 Standards   ETL/UL651
 Dimensions   3.75"D x 4.50"W x 7.5"L
 Color   Grey or customized to suit your project needs
 Application   Underground and above construction
 Feature    Character-flame resistant, UV resistant, corrosion resistant, etc
 Custom made     Flexiable OEM/ODM-size, colors, packaging can be customized
 Tensile strength   5,000 psi (3.45 KN/cm²)
 Extrusion   Fusion
 Water absorption   0.50% of whole weight after soak
 Resistance to crushing   ID≥70% after test
 Resistance to impact      Less than 3 of 1/32 inch cracks & tears
 Deflection unde load     0.25mm deformation
 Fire rating       UL 94V-0
 Resistance to specific reagents    Less ±2.50% weight after 60 / 120 days soak
 Permanency of printing       Yes
 Rust & sunlight Resistant     Yes
 Shipping     By sea
 Samples        Available







Markings

Markings shall be permanent, legible, and visible after the product is installed. The following types

of markings or the equivalent are considered permanent:

(A) Etched,

(B) Molded,

(C) Die stamped,

(D) Paint stenciled and

(E) Indelibly stamped on a pressure sensitive label secured by adhesive and complying with the Standard for Marking and Labeling Systems, UL 969.

Information to be marked on conduits



(1) What is ETL Pvc Electrical Junction Box?

ETL junction boxes are suitable for circuit protector sockets and electrical accessories such as switches, panels, junction boxes, etc. The technical specifications comply with the electrical specifications of American standards such as the United States, Canada, and Mexico.

Also known as an electrical box\connection box\terminal box.

(2)What is ETL Pvc Electrical Junction Box used for?

The function of a junction box is to serve as a box for connecting and branching wires and cables, playing a critical role in electrical installation. It ensures the safety and orderliness of the electrical system, making it convenient for electricians to connect and manage wires. Junction boxes are commonly used in places such as homes, offices, and factories that require electrical wiring, and are an indispensable part of electrical systems.

These include

(1) Concealed installations  (2) Supporting conduit bodies  (3) Areas with cinders  (4) Wet iocations

(5) Dry and damp iocations  (6) Exposed installations  (7) Underground installations

(8) Environments with corrosive influences



(3)Here’s What Sets us Apart

Certification: Our PVC electrical junction box conforms to the requirements of ul and ETL standards and has excellent safety.

New materials: Made with 100% new materials, pursuing ultimate quality and performance.

Excellent fire resistance: UL 94V-0 Fire rating ensures rapid fire extinguishing, providing protection for your home or building.

Unparalleled durability: Heat resistance, sun resistance, and corrosion resistance ensure a long-lasting and reliable solution.

Strength:ETL is a leading manufacturer of high-quality electrical conduits, trusted by industry professionals for 10 Years+.ETL bringing you complete, beneficial, convenient, and high-quality electrical conduit and accessory products.

(4)We believe in

Safety first: Building reliable and safe electrical systems.

Quality craftsmanship: Precise engineering and attention to detail.

Customer satisfaction: Providing exceptional support and solutions.



Get exclusive solutions for your project immediately!

Contact ETL >>   to learn about the differences in high-quality electrical conduits



Built for strength and safety comply with US market standards.

Our ETL electrical junction box are designed to handle even the most demanding electrical projects.

(1)Extraordinary strength: Can withstand up to 5,000 psi tensile force.

(2)Flexible deflection: Minimizes risks with a mere 0.25mm deflection under load.

(3)Industry-leading compliance: Meets and exceeds ul651 and ETL standards for ultimate peace of mind.

140x140
140x140

Our electrical junction box are crafted from premium-grade, 100% brand-new materials.

(1)Superior quality: ETL electrical junction box have a series of impressive advantages: heat resistance, corrosion resistance, fire resistance, and sun resistance. (2)Increased efficiency: Save money by avoiding costly delays.

(3)Effortless installation: No more time-consuming prep work before installation.



UL 94V-0 fire resistance rating enhanced fire safety, designed for you.

(1)Rapid extinguishing: The fire is quickly extinguished when the fire source is cut off.

(2)Harmless safety: Using ETL electrical junction box,This advanced technology minimizes potential damage and keeps you and your property protected.

140x140
140x140

Sunlight resistance built for the outdoors.

our electrical conduit pipes excel in outdoor installations.

(1)Heat resistance: Sunlight & UV resistance support.

(2)UV resistance: Stands strong against the damaging effects of sunlight.



Non - metallic conduit strong and reliable.

(1)Lightweight construction: Easy to handle and install.

(2)Cost-effective solution:More durable and affordable than metal pipes, with cheaper shipping costs.

(3)Corrosion-proof: Enjoy lasting performance with guaranteed protection against rust.

140x140
140x140

Trusted partner.

With over 10 years of experience in the foreign trade of plastic piping.

ETL produce and distribute nationwide, providing one-to-one services to numerous companies in various countries such as the united states and australia.

our professional team can tailor perfect solutions according to your unique needs. experience the safety and reliability of ETL electrical conduits!





140x140

(1)Airport electric power facilities

140x140

(2)Highway transportation infrastructure power projects

140x140

(3)Industrial Park Power Supplying System



140x140

(4)Smart Grid and New Energypower Generation Projects



140x140

(5)Urban Power Grid Construction Projects



Get the full price list now by contact our sales team.  >>





(1)OEM&ODM

OEM/ODM options are available for sizes, colors, and packaging.

(2)Quality

Provide overall solutions for various high-quality plastic pipes and accessories products.

(3)Price

Can be negotiable with flexible solution.

(4)Main Business

Supply PVC Electrical Conduit & Fittings:

(1) Rigid and corrugated conduit and fittings for electrical, building, and communication projects. SCH40, SCH80, DB60, DB100, DB120, TYPE A, TYPE EB PVC electrical conduit and fittings (UL & ASTM certified)

(2) Heavy duty & medium duty conduit (AS/NZS Certified)

(3) DB2 & ENT conduit (CSA & CUL certified)

(4) Solar conduit (IEC & AS/NZS certified)

(5) ETL rigid & corrugated conduit (IEC & ISO certified) and that's just the tip of the lceberg!

(6) We also offer a wide variety of electrical box, bend, coupling, tee, elbow,ib bodies, reducer, connectors, adapter, bushing, cap and more.





Contact ETL >>

Now to discuss your project and help you reduce project costs get a free quote today !







Applications of ETL and ul651 Pvc-u Electrical Junction Switch and Outlet Box



ETL and ul651 upvc electrical junction switch and outlet box are highly versatile and widely used across various sectors due to their durability, non-conductive properties, and resistance to environmental factors. Below are some of their key applications:



  1. Airport Electric Power Facilities: Upvc electrical junction switch and outlet box play a crucial role in ensuring the safe and efficient distribution of electrical power in airport facilities. They protect critical wiring systems in terminals, runways, and lighting systems, which are essential for smooth operations and passenger safety.



  1. Highway Transportation Infrastructure Power Projects: In highway systems, ETL and ul651 upvc electrical junction switch and outlet box provide robust protection for power cables that support lighting, signaling, and surveillance systems. Their resilience to mechanical stress and environmental exposure ensures long-term reliability in harsh outdoor conditions.



  1. Industrial Park Power Supplying System: Industrial parks often require complex and high-capacity power distribution networks. ETL and ul651 upvc electrical junction switch and outlet box safeguard the electrical wiring from mechanical damage, chemical exposure, and moisture, ensuring stable and uninterrupted power supply for manufacturing and other industrial activities.



  1. Smart Grid and New Energy Power Generation Projects: In modern power infrastructure, including smart grids and renewable energy projects such as solar and wind farms, ETL and ul651 upvc electrical junction switch and outlet box protect wiring and cabling systems. Their insulation properties and resistance to UV rays make them ideal for outdoor installations in these innovative energy solutions.



  1. Urban Power Grid Construction Projects: In urban environments, ETL and ul651 upvc electrical junction switch and outlet box are indispensable for constructing underground and overhead power grids. Junction box provide a secure pathway for cables, ensuring reliable power distribution to residential, commercial, and public facilities while minimizing the risk of electrical faults or hazards.
