Color:Grey or Customized
Size:1.75"D x 5.5"W x 6"L
1-Gang 18 Cu.In. Shallow New Work Electrical Outlet/Switch Box
18 Cu.In. One-Gang New Work Shallow Box with Captive Nails
ETL Pvc-u Electrical Junction box
Modle | 1-Gang 18 Cu.In. Shallow New Work Electrical Outlet/Switch Box | |||||||
18 Cu.In. One-Gang New Work Shallow Box with Captive Nails | ||||||||
Raw material | PVC | |||||||
Standards | ETL/UL651 | |||||||
Dimensions | 1.75"D x 5.5"W x 6"L | |||||||
Color | Grey or customized to suit your project needs | |||||||
Application | Underground and above construction | |||||||
Feature | Character-flame resistant, UV resistant, corrosion resistant, etc | |||||||
Custom made | Flexiable OEM/ODM-size, colors, packaging can be customized | |||||||
Tensile strength | 5,000 psi (3.45 KN/cm²) | |||||||
Extrusion | Fusion | |||||||
Water absorption | ﹤0.50% of whole weight after soak | |||||||
Resistance to crushing | ID≥70% after test | |||||||
Resistance to impact | Less than 3 of 1/32 inch cracks & tears | |||||||
Deflection unde load | ﹤0.25mm deformation | |||||||
Fire rating | UL 94V-0 | |||||||
Resistance to specific reagents | Less ±2.50% weight after 60 / 120 days soak | |||||||
Permanency of printing | Yes | |||||||
Rust & sunlight Resistant | Yes | |||||||
Shipping | By sea | |||||||
Samples | Available |
Markings
Markings shall be permanent, legible, and visible after the product is installed. The following types
of markings or the equivalent are considered permanent:
(A) Etched,
(B) Molded,
(C) Die stamped,
(D) Paint stenciled and
(E) Indelibly stamped on a pressure sensitive label secured by adhesive and complying with the Standard for Marking and Labeling Systems, UL 969.
Information to be marked on conduits
(1) What is ETL Pvc Electrical Junction Box?
ETL junction boxes are suitable for circuit protector sockets and electrical accessories such as switches, panels, junction boxes, etc. The technical specifications comply with the electrical specifications of American standards such as the United States, Canada, and Mexico.
Also known as an electrical box\connection box\terminal box.
(2)What is ETL Pvc Electrical Junction Box used for?
The function of a junction box is to serve as a box for connecting and branching wires and cables, playing a critical role in electrical installation. It ensures the safety and orderliness of the electrical system, making it convenient for electricians to connect and manage wires. Junction boxes are commonly used in places such as homes, offices, and factories that require electrical wiring, and are an indispensable part of electrical systems.
These include
(1) Concealed installations (2) Supporting conduit bodies (3) Areas with cinders (4) Wet iocations
(5) Dry and damp iocations (6) Exposed installations (7) Underground installations
(8) Environments with corrosive influences
(3)Here’s What Sets us Apart
Certification: Our PVC electrical junction box conforms to the requirements of ul and ETL standards and has excellent safety.
New materials: Made with 100% new materials, pursuing ultimate quality and performance.
Excellent fire resistance: UL 94V-0 Fire rating ensures rapid fire extinguishing, providing protection for your home or building.
Unparalleled durability: Heat resistance, sun resistance, and corrosion resistance ensure a long-lasting and reliable solution.
Strength:ETL is a leading manufacturer of high-quality electrical conduits, trusted by industry professionals for 10 Years+.ETL bringing you complete, beneficial, convenient, and high-quality electrical conduit and accessory products.
(4)We believe in
Safety first: Building reliable and safe electrical systems.
Quality craftsmanship: Precise engineering and attention to detail.
Customer satisfaction: Providing exceptional support and solutions.
Get exclusive solutions for your project immediately!
Contact ETL >> to learn about the differences in high-quality electrical conduits.
Our ETL electrical junction box are designed to handle even the most demanding electrical projects.
(1)Extraordinary strength: Can withstand up to 5,000 psi tensile force.
(2)Flexible deflection: Minimizes risks with a mere 0.25mm deflection under load.
(3)Industry-leading compliance: Meets and exceeds ul651 and ETL standards for ultimate peace of mind.
(1)Superior quality: ETL electrical junction box have a series of impressive advantages: heat resistance, corrosion resistance, fire resistance, and sun resistance. (2)Increased efficiency: Save money by avoiding costly delays.
(3)Effortless installation: No more time-consuming prep work before installation.
(1)Rapid extinguishing: The fire is quickly extinguished when the fire source is cut off.
(2).Harmless safety: Using ETL electrical junction box,This advanced technology minimizes potential damage and keeps you and your property protected.
our electrical conduit pipes excel in outdoor installations.
(1)Heat resistance: Sunlight & UV resistance support.
(2)UV resistance: Stands strong against the damaging effects of sunlight.
(1)Lightweight construction: Easy to handle and install.
(2)Cost-effective solution:More durable and affordable than metal pipes, with cheaper shipping costs.
(3)Corrosion-proof: Enjoy lasting performance with guaranteed protection against rust.
With over 10 years of experience in the foreign trade of plastic piping.
ETL produce and distribute nationwide, providing one-to-one services to numerous companies in various countries such as the united states and australia.
our professional team can tailor perfect solutions according to your unique needs. experience the safety and reliability of ETL electrical conduits!
Get the full price list now by contact our sales team. >>
(1)OEM&ODM
OEM/ODM options are available for sizes, colors, and packaging.
(2)Quality
Provide overall solutions for various high-quality plastic pipes and accessories products.
(3)Price
Can be negotiable with flexible solution.
(4)Main Business
Supply PVC Electrical Conduit & Fittings:
(1) Rigid and corrugated conduit and fittings for electrical, building, and communication projects. SCH40, SCH80, DB60, DB100, DB120, TYPE A, TYPE EB PVC electrical conduit and fittings (UL & ASTM certified)
(2) Heavy duty & medium duty conduit (AS/NZS Certified)
(3) DB2 & ENT conduit (CSA & CUL certified)
(4) Solar conduit (IEC & AS/NZS certified)
(5) ETL rigid & corrugated conduit (IEC & ISO certified) and that's just the tip of the lceberg!
(6) We also offer a wide variety of electrical box, bend, coupling, tee, elbow,ib bodies, reducer, connectors, adapter, bushing, cap and more.
